TPS73133MDBVREP

具有反向电流保护无电容NMOS 150毫安低压差稳压器 CAP-FREE NMOS 150 mA LOW DROPOUT REGULATOR WITH REVERSE CURRENT PROTECTION

Linear Voltage Regulator IC 1 Output 150mA SOT-23-5

立创商城:
TPS73133MDBVREP

德州仪器TI:
Enhanced product, cap-free NMOS, 150-mA low-dropout regulator with reverse current protection

艾睿:
If you need to maintain a steady voltage on your circuit, then this LDO TPS73133MDBVREP linear regulator from Texas Instruments is perfect for you! It has an overall accuracy of ±0.5 %. This device has a maximum power dissipation of 638 mW. Its typical dropout voltage at current is 0.03@150mA V. This voltage regulation device&s;s single output can produce a current up to 0.15 A. It only needs a voltage of at least 1.7 V while not exceeding 5.5 V to effectively power your circuit. With a fixed output that has a voltage of 3.3 V, this is power management at its best. At a load regulation of 0.002%/ATyp and line regulation of 0.01%/VTyp your circuit is capable of maintaining a constant voltage level at your output. Its maximum power dissipation is 638 mW. This product will be shipped in tape and reel packaging for quick mounting and safe delivery. This voltage regulation device has an operating temperature range of -55 °C to 125 °C. The maximum dropout voltage is 0.1@150mA V. Its polarity is positive.

安富利:
LDO Regulator Pos 3.3V 0.15A 5-Pin SOT-23 T/R

Chip1Stop:
LDO Regulator Pos 3.3V 0.15A 5-Pin SOT-23 T/R

Verical:
LDO Regulator Pos 3.3V 0.15A 5-Pin SOT-23 T/R

Newark:
# TEXAS INSTRUMENTS  TPS73133MDBVREP  Fixed LDO Voltage Regulator, 1.7V to 5.5V, 30mV Dropout, 3.3Vout, 150mAout, SOT-23-5
