TPS73118MDBVREP

具有反向电流保护无电容NMOS 150毫安低压差稳压器 CAP-FREE NMOS 150 mA LOW DROPOUT REGULATOR WITH REVERSE CURRENT PROTECTION

Linear Voltage Regulator IC 1 Output 150mA SOT-23-5

得捷:
IC REG LINEAR 1.8V 150MA SOT23-5

立创商城:
TPS73118MDBVREP

德州仪器TI:
Enhanced product, cap-free NMOS, 150-mA low-dropout regulator with reverse current protection

艾睿:
Use the LDO TPS73118MDBVREP linear regulator from Texas Instruments to maintain a constant output voltage. It has an overall accuracy of ±0.5 %. This device has a maximum power dissipation of 638 mW. Its typical dropout voltage at current is 0.03@150mA V. This voltage regulation device&s;s single output can produce a current up to 0.15 A. Using the part will provide the power your application needs by requiring a voltage only of 1.7 V and not exceeding a voltage of 5.5 V. With a fixed output that has a voltage of 1.8 V, this is power management at its best. Operate at a constant current by utilizing the load regulation of 0.002%/ATyp and line regulation of 0.01%/VTyp. Its maximum power dissipation is 638 mW. In order to guarantee safe delivery and allow for quick mounting of this component after delivery, it will be enclosed in tape and reel packaging during shipment. Its polarity is positive. The maximum dropout voltage is 0.1@150mA V. This voltage regulation device has a minimum operating temperature of -55 °C and a maximum of 125 °C.

安富利:
LDO Regulator Pos 1.8V 0.15A 5-Pin SOT-23 T/R

Chip1Stop:
LDO Regulator Pos 1.8V 0.15A 5-Pin SOT-23 T/R

Verical:
LDO Regulator Pos 1.8V 0.15A 5-Pin SOT-23 T/R

Newark:
# TEXAS INSTRUMENTS  TPS73118MDBVREP  Fixed LDO Voltage Regulator, 1.7V to 5.5V, 30mV Dropout, 1.8Vout, 150mAout, SOT-23-5

Win Source:
Linear Voltage Regulator IC Positive Fixed 1 Output 1.8V 150mA SOT-23-5
