TEXAS INSTRUMENTS TPS62742DSST 直流-直流开关降压逐步递减稳压器, 可调, 2.2V-5.5V输入, 1.8V-3.3V输出, 400mA输出, WSON-12
降压直流/直流转换器(集成开关)最大输入高达 6V,TPS 系列,Texas Instruments
立创商城:
TPS62742DSST
德州仪器TI:
3V-5.5V input, 360-nA Iq step-down converter with 400mA and integrated load switch
得捷:
IC REG CONV BLUETTH 1OUT 12WSON
欧时:
降压直流/直流转换器(集成开关)最大输入高达 6V,TPS 系列,Texas Instruments### 直流/直流开关调节器转换器(集成开关),Texas InstrumentsTexas Instruments 的此系列高度集成的高效开关稳压器包括步升(升压)、步降(降压)、步升/降(增压/降压)和反相类型,为每个直流稳压器应用提供高效的解决方案。
贸泽:
Switching Voltage Regulators 360nA Iq Step-Down Converter
e络盟:
直流-直流开关降压逐步递减稳压器, 可调, 2.2V-5.5V输入, 1.8V-3.3V输出, 400mA输出, WSON-12
艾睿:
Adjust the voltage level of your devices with this step down TPS62742DSST DC to DC converter from Texas Instruments. This converter&s;s single output can produce a current up to 0.4 A. Using the part will provide the power your application needs by requiring a voltage only of 2.2 V and not exceeding a voltage of 5.5 V. With an adjustable output that has a voltage of 1.8 to 3.3 V, this is power management at its best. By operating at a load regulation of 0.001%/mA and line regulation of 0%/V you can provide a constant voltage at your output. This device has a typical switch current of 0.65 A. You can operate this at a switching frequency of 2000 kHz. This converter has a minimum operating temperature of -40 °C and a maximum of 85 °C.
安富利:
Conv DC-DC Single Step Down 2.2V to 5.5V 12-Pin WSON T/R
Verical:
Conv DC-DC 2.2V to 5.5V Step Down Single-Out 1.8V to 3.3V 0.4A 12-Pin WSON EP T/R
Newark:
DC-DC Switching Buck Step Down Regulator, Adjustable, 2.2V-5.5Vin, 1.8V-3.3Vout, 400mAout, WSON-12
DeviceMart:
IC REG BUCK ADJ 400MA 12WSON
输出接口数 1
输出电压 1.8V ~ 3.3V
输出电流 400 mA
针脚数 12
静态电流 300 nA
调节输出数 1
开关频率 2 MHz
拓扑结构 Buck
开关电流 0.65 A
输入电压Max 5.5 V
输入电压Min 2.2 V
输出电压Max 3.3 V
输出电压Min 1.8 V
输出电流Max 400 mA
工作温度Max 85 ℃
工作温度Min -40 ℃
电源电压Min 2.2 V
输入电压 2.2V ~ 5.5V
安装方式 Surface Mount
引脚数 12
封装 WSON-12
长度 3.1 mm
宽度 2.1 mm
高度 0.75 mm
封装 WSON-12
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Cut Tape CT
制造应用 转换器,蓝牙(BLT)
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/06/15
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
TPS62742DSST TI 德州仪器 | 当前型号 | 当前型号 |
TPS62742DSSR 德州仪器 | 类似代替 | TPS62742DSST和TPS62742DSSR的区别 |
