TPS7325QP

具有集成延迟复位功能的低压差稳压器 LOW-DROPOUT VOLTAGE REGULATORS WITH INTEGRATED DELAYED RESET FUNCTION

PMIC - 稳压器 - 线性 正 固定 1 输出 500mA 8-PDIP

立创商城:
TPS7325QP

德州仪器TI:
500-mA, 10-V, low-dropout voltage regulator with power good & enable

得捷:
IC REG LINEAR 2.5V 500MA 8DIP

贸泽:
LDO Voltage Regulators Low-Dropout Voltage Regulator

艾睿:
Don&s;t let unpredictable voltage levels ruin your circuit! Use this LDO TPS7325QP linear regulator from Texas Instruments to control your voltage levels! Its typical dropout voltage at current is 0.005@10mA|0.27@500mA|0.05@100mA V. This device has a maximum power dissipation of 1175 mW. It has an overall accuracy of ±3 %. This voltage regulation device&s;s single output can produce a current up to 0.5 A. With a small input voltage of 3.1 V and a max of 10 V, this will supply sufficient power to your circuit. With a fixed output that has a voltage of 2.5 V, this is power management at its best. To produce a constant current at your output, supply your circuit with a load regulation of 60mV and line regulation of 20mV. Its maximum power dissipation is 1175 mW. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. Its polarity is positive. The maximum dropout voltage is 0.014@10mA|0.08@100mA|0.4@500mA V. This voltage regulation device has an operating temperature range of -40 °C to 125 °C.

安富利:
LDO Regulator Pos 2.5V 0.5A 8-Pin PDIP Tube

Chip1Stop:
Single Channel LDO Single Output LDO, 500mA, Fixed2.5V, Integrated SVS, Low Quiescent Current LDO Regulator Pos 2.5V 0.5A 8-Pin PDIP Tube

Verical:
LDO Regulator Pos 2.5V 0.5A 8-Pin PDIP Tube
