具有集成延迟复位功能的低压差稳压器 LOW-DROPOUT VOLTAGE REGULATORS WITH INTEGRATED DELAYED RESET FUNCTION
PMIC - 稳压器 - 线性 正 固定 输出 500mA 20-TSSOP
得捷:
IC REG LINEAR 5V 500MA 20TSSOP
立创商城:
TPS7350QPWR
德州仪器TI:
500-mA, 10-V, low-dropout voltage regulator with power good & enable
艾睿:
Control the voltage level of your circuit with this LDO TPS7350QPWR linear regulator from Texas Instruments. It has an overall accuracy of ±2 %. This device has a maximum power dissipation of 700 mW. Its typical dropout voltage at current is 0.0029@10mA|0.027@100mA|0.146@500mA V. This voltage regulation device&s;s single output can produce a current up to 0.5 A. The best way to provide power to your application is by using this, which needs a voltage of at least 5.33 V and no higher than 10 V. With a fixed output that has a voltage of 5 V, this is power management at its best. Users like the load regulation of 65mV and line regulation of 25mV. Its maximum power dissipation is 700 mW. Tape and reel packaging will encase the product during shipment, ensuring safe delivery and enabling quick mounting of components. The maximum dropout voltage is 0.006@10mA|0.035@100mA|0.17@500mA V. Its polarity is positive. This voltage regulation device has a minimum operating temperature of -40 °C and a maximum of 125 °C.
安富利:
LDO Regulator Pos 5V 0.5A 20-Pin TSSOP T/R
Chip1Stop:
Single Channel LDO Single Output LDO, 500mA, Fixed5.0V, Integrated SVS, Low Quiescent Current LDO Regulator Pos 5V 0.5A 20-Pin TSSOP T/R
Verical:
LDO Regulator Pos 5V 0.5A 20-Pin TSSOP T/R
输出接口数 1
输入电压DC 10.0V max
输出电压 5 V
输出电流 500 mA
供电电流 65 µA
耗散功率 0.7 W
静态电流 0.34 mA
输出电容类型 Ceramic
跌落电压 0.027V @100mA,0.0029V @10mA,0.146V @500mA
调节输出数 1
输入电压Max 10 V
输入电压Min 5.33 V
输出电压Min 5 V
输出电流Max 0.5 A
工作温度Max 125 ℃
工作温度Min -40 ℃
耗散功率Max 700 mW
精度 ±2 %
输入电压 10V ~ 5.33V
安装方式 Surface Mount
引脚数 20
封装 TSSOP-20
封装 TSSOP-20
工作温度 -40℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
TPS7350QPWR TI 德州仪器 | 当前型号 | 当前型号 |
