TPS7301QP

PMOS稳压器

PMIC - 稳压器 - 线性 正 可调式 输出 500mA 8-PDIP

得捷:
IC REG LINEAR POS ADJ 500MA 8DIP

立创商城:
TPS7301QP

德州仪器TI:
500-mA, 10-V, low-dropout voltage regulator with power good & enable

贸泽:
低压差稳压器 Lowest Dropout PMOS

艾睿:
This LDO TPS7301QP linear regulator developed by Texas Instruments keeps the power stable! Its typical dropout voltage at current is 0.146@500mA V. It has an overall accuracy of ±3 %. This device has a maximum power dissipation of 1175 mW. This voltage regulation device&s;s single output can produce a current up to 0.5 A. It only needs a voltage of at least 2.47 V while not exceeding 10 V to effectively power your circuit. With an adjustable output that has a voltage of 1.2 to 9.75 V, this is power management at its best. Maintain a constant voltage level with a load regulation of 22mV and line regulation of 18mV. Its maximum power dissipation is 1175 mW. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. This voltage regulation device has an operating temperature range of -40 °C to 125 °C. Its polarity is positive.

安富利:
LDO Regulator Pos 1.2V to 9.75V 0.5A 8-Pin PDIP Tube

Chip1Stop:
Single Channel LDO Single Output LDO, 500mA, Adj.1.2 to 9.75V, Integrated SVS, Low Quiescent Current LDO Regulator Pos 1.2V to 9.75V 0.5A 8-Pin PDIP Tube

Verical:
LDO Regulator Pos 1.2V to 9.75V 0.5A 8-Pin PDIP Tube

力源芯城:
带电压监测的低压差PMOS稳压器

DeviceMart:
IC REG LDO ADJ .5A 8-DIP
