USB充电端口控制器和电源开关,负载检测 USB Charging Port Controller and Power Switch with Load Detection
电源开关/驱动器 1:1 N 通道 3A 16-WQFN(3x3)
得捷:
IC PWR SWITCH N-CHAN 1:1 16WQFN
贸泽:
电源开关 IC - 配电 Auto USB Chrg Port Pwr Switch & Cntlr
艾睿:
Use this usb charging port TPS2543QRTERQ1 USB powered Ethernet switch from Texas Instruments to control which one of your devices draws power. Using the part will provide the power your application needs by requiring a voltage only of 4.5 V and not exceeding a voltage of 5.5 V. Its current limit is 2.97 A. This component will be shipped in tape and reel packaging for effective mounting and safe delivery. This USB powered network switch has an operating temperature range of -40 °C to 125 °C.
安富利:
USB Charging Port Controller and Power Switch 16-Pin WQFN T/R
Verical:
USB Power SW USB Charging Port Controller Single 5.5V 2.97A Automotive 16-Pin WQFN EP T/R
输出接口数 1
输出电流 2.5 A
上升时间 1000 µs
输入电压Max 5.5 V
输入电压Min 4.5 V
输出电流Max 3 A
下降时间 350 µs
工作温度Max 125 ℃
工作温度Min -40 ℃
输入电压 4.5V ~ 5.5V
安装方式 Surface Mount
引脚数 16
封装 WFQFN-16
封装 WFQFN-16
工作温度 -40℃ ~ 125℃ TJ
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
TPS2543QRTERQ1 TI 德州仪器 | 当前型号 | 当前型号 |
TPS2543RTER 德州仪器 | 完全替代 | TPS2543QRTERQ1和TPS2543RTER的区别 |
TPS2543QRTETQ1 德州仪器 | 完全替代 | TPS2543QRTERQ1和TPS2543QRTETQ1的区别 |
TPS2546RTET 德州仪器 | 完全替代 | TPS2543QRTERQ1和TPS2546RTET的区别 |
