Step-Up Boost DC/DC Converters Integrated Switch, Texas Instruments### 直流/直流开关调节器转换器(集成开关),Texas InstrumentsTexas Instruments 的此系列高度集成的高效开关稳压器包括步升(升压)、步降(降压)、步升/降(增压/降压)和反相类型,为每个直流稳压器应用提供高效的解决方案。
Step-Up Boost DC/DC Converters Integrated Switch, Texas Instruments
### 直流/直流开关调节器转换器(集成开关),Texas Instruments
Texas Instruments 的此系列高度集成的高效开关稳压器包括步升(升压)、步降(降压)、步升/降(增压/降压)和反相类型,为每个直流稳压器应用提供高效的解决方案。
得捷:
IC REG BOOST 5V 1.2A 10WSON
立创商城:
升压型 Vin=0.3V~5.5V Vout=5V 1.2A
德州仪器TI:
0.3-V input voltage, 5-V fixed output voltage boost converter with 1.3-A switches, 3-mm x 3-mm QF
欧时:
### Step-Up Boost DC/DC Converters Integrated Switch, Texas Instruments### 直流/直流开关调节器转换器(集成开关),Texas InstrumentsTexas Instruments 的此系列高度集成的高效开关稳压器包括步升(升压)、步降(降压)、步升/降(增压/降压)和反相类型,为每个直流稳压器应用提供高效的解决方案。
艾睿:
Adjust the voltage level of your devices with this step up TPS61202DSCT DC to DC converter from Texas Instruments. This converter&s;s single output can produce a current up to 0.6 A. Use this part at voltages between 0.3 V and 5.5 V. With a fixed output that has a voltage of 5 V, this is power management at its best. This converter is 90typ % efficient. At a load regulation of 0.1%Typ and line regulation of 0.1%Typ a constant current can be produced at the output of your circuit. This part offers a switching frequency of 1650 kHz in order to work properly. Tape and reel packaging will encase this product during shipment, in order to ensure safe delivery and enable quick mounting of components. This converter has a minimum operating temperature of -40 °C and a maximum of 85 °C.
安富利:
Conv DC-DC Single Step Up 0.3V to 5.5V 10-Pin WSON EP T/R
Chip1Stop:
Step-Up Regulator 0.3V Input Voltage Boost Converter with 1.3A Switches and 'Down Mode' in a 3x3 QFN Conv DC-DC Single Step Up 0.3V to 5.5V 10-Pin WSON EP T/R
Verical:
Conv DC-DC 0.3V to 5.5V Synchronous Step Up Single-Out 5V 0.6A 10-Pin WSON EP T/R
Newark:
# TEXAS INSTRUMENTS TPS61202DSCT Synchronous Boost Step Up Switching Regulator, Fixed, 300 mV to 5.5Vin, 5V/600mA out, SON-10
DeviceMart:
IC REG BOOST SYNC 5V 0.6A 10WSON
输出接口数 1
输出电压 5 V
输出电流 600 mA
静态电流 50.0 µA
调节输出数 1
输出功率 2.05 W
开关频率 1.25MHz ~ 1.65MHz
拓扑结构 Boost
输入电压Max 5.5 V
输入电压Min 0.3 V
输出电压Max 5.05 V
输出电压Min 5 V
输出电流Max 600 mA
工作温度Max 85 ℃
工作温度Min -40 ℃
电源电压 0.3 V
输入电压 0.3V ~ 5.5V
安装方式 Surface Mount
引脚数 10
封装 WSON-10
长度 3 mm
宽度 3 mm
高度 0.75 mm
封装 WSON-10
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/06/15
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
TPS61202DSCT TI 德州仪器 | 当前型号 | 当前型号 |
TPS61202DSCR 德州仪器 | 类似代替 | TPS61202DSCT和TPS61202DSCR的区别 |
TPS61202DSCTG4 德州仪器 | 类似代替 | TPS61202DSCT和TPS61202DSCTG4的区别 |
TPS61202DSCRG4 德州仪器 | 功能相似 | TPS61202DSCT和TPS61202DSCRG4的区别 |
