TPS2041BMDBVTEP

TEXAS INSTRUMENTS  TPS2041BMDBVTEP  电源分配开关, 限流, 低电平有效, 1路输出, 5.5V, 1A, SOT-23-5

The is a Power Distribution Switch intended for applications where heavy capacitive loads and short circuits are likely to be encountered. This device incorporates 70mR N-channel MOSFET power switches for power-distribution systems. Each switch is controlled by a logic enable input. Gate drive is provided by an internal charge pump designed to control the power-switch rise and fall times to minimize current surges during switching. The charge pump requires no external components and allows operation from supplies as low as 2.7V. When the output load exceeds the current-limit threshold or a short is present, the device limits the output current to a safe level by switching into a constant-current mode, pulling the overcurrent OC logic output low. When continuous heavy overloads and short circuits increase the power dissipation in the switch, causing the junction temperature to rise, a thermal protection circuit shuts off the switch to prevent damage.

.

500mA Continuous current

.

Thermal and short-circuit protection

.

0.6ms Typical rise time

.

Undervoltage lockout

.

Deglitched fault report OC

.

No OC glitch during power up

.

1µA Maximum standby supply current
