2 -A双非同步转换器,集成高边MOSFET 2-A DUAL NON-SYNCHRONOUS CONVERTER WITH INTEGRATED HIGH-SIDE MOSFET
降压 开关稳压器 IC 正 可调式 0.8V 2 输出 2A 14-PowerTSSOP(0.173",4.40mm 宽)
得捷:
IC REG BUCK ADJ 2A DL 14HTSSOP
立创商城:
降压型 Vin=4.5V~28V Vout=800mV~25.2V 2A
德州仪器TI:
4.5V to 28V Input, Dual 2A Output, 300kHz Step-Down Converter with Internal Compensation
艾睿:
Adjust the voltage level of your devices with this step down TPS54283PWPR DC to DC converter from Texas Instruments. This converter&s;s 2 outputs can produce a current up to 2 A. Use this part at voltages between 4.5 V and 28 V. With an adjustable output that has a voltage of 0.8 to 25.2 V, this is power management at its best. This converter is 85typ % efficient. This part offers a switching frequency of 375 kHz in order to work properly. Tape and reel packaging will encase the product during shipment, ensuring safe delivery and enabling quick mounting of components. This converter has an operating temperature range of -40 °C to 85 °C.
安富利:
Conv DC-DC Dual Step Down 4.5V to 28V 14-Pin HTSSOP EP T/R
Chip1Stop:
Step-Down Regulator Dual 2A Non-Synchronous Step Down SWIFT? Converter with Integrated High Side MOSFET, 300 kHz Conv DC-DC Dual Step Down 4.5V to 28V 14-Pin HTSSOP EP T/R
Verical:
Conv DC-DC 4.5V to 28V Synchronous Step Down Dual-Out 0.8V to 25.2V 2A/2A 14-Pin HTSSOP EP T/R
Newark:
# TEXAS INSTRUMENTS TPS54283PWPR DC/DC CONV, BUCK, 310KHZ, HTSSOP-14
Win Source:
Buck Switching Regulator IC Positive Adjustable 0.8V 2 Output 2A 14-TSSOP 0.173", 4.40mm Width Exposed Pad
DeviceMart:
IC REG BUCK ADJ 2A DL 14HTSSOP
输出接口数 2
输出电压 0.8V ~ 25.2V
输出电流 2 A
针脚数 14
静态电流 1.80 mA
调节输出数 2
输出功率 1.6 W
开关频率 310 kHz
过温保护 Yes
拓扑结构 Buck
输入电压Max 28 V
输入电压Min 4.5 V
输出电压Max 25.2 V
输出电压Min 0.8 V
输出电流Max 2 A
工作温度Max 85 ℃
工作温度Min -40 ℃
电源电压 4.5 V
输入电压 4.5V ~ 28V
安装方式 Surface Mount
引脚数 14
封装 HTSSOP-14
封装 HTSSOP-14
工作温度 -40℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
制造应用 电源管理, 通信与网络, 消费电子产品
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/06/15
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
TPS54283PWPR TI 德州仪器 | 当前型号 | 当前型号 |
TPS54283PWP 德州仪器 | 类似代替 | TPS54283PWPR和TPS54283PWP的区别 |
TPS54283PWPG4 德州仪器 | 类似代替 | TPS54283PWPR和TPS54283PWPG4的区别 |
TPS54283PWPRG4 德州仪器 | 类似代替 | TPS54283PWPR和TPS54283PWPRG4的区别 |
