7.62 mm 45° 3200 mlm 透明 2.1 V 通孔 Telux LED
黄色 590nm 指示 - 分立 2.1V 4-DIP(0.200",5.08mm)
得捷:
LED YELLOW CLEAR 4DIP T/H
贸泽:
标准LED-通孔 Yellow Clr Non-Diff
e络盟:
VISHAY TLWY8900 发光二极管, 黄色, 通孔安装, 1.65mm, 70 mA, 2.1 V, 590 nm
艾睿:
LED Uni-Color Yellow 594nm Automotive 4-Pin Tube
富昌:
黄色 7.62 mm 45° 3200 mlm 透明 2.1 V 通孔 Telux LED
Chip1Stop:
LED Uni-Color Yellow 594nm Automotive 4-Pin Tube
Verical:
LED Uni-Color Yellow 594nm Automotive 4-Pin Tube
AMEYA360:
LED TELUX 4PIN YELLOW 3000MLM
正向电压 2.1 V
波长 590 nm
发光强度 0.7 mcd
视角 45°
峰值波长 594 nm
耗散功率 187 W
测试电流 70 mA
正向电流 70 mA
正向电流Max 70 mA
工作温度Max 110 ℃
工作温度Min -40 ℃
耗散功率Max 187 mW
安装方式 Through Hole
引脚数 4
封装 DIP-4
长度 7.62 mm
宽度 7.62 mm
高度 4.05 mm
脚长度 4.95 mm
封装 DIP-4
颜色 Yellow
工作温度 -40℃ ~ 110℃
产品生命周期 Active
包装方式 Tube
制造应用 Lighting, Signalling, 车用
RoHS标准 RoHS Compliant
含铅标准 Lead Free
