TEXAS INSTRUMENTS TPS53126PW 直流/直流控制器, D-CAP2+模式, 4.5V至24V, 2路输出, 同步降压, 700kHz, TSSOP-24
Do you have to step up or down from one voltage level to another? The Texas Instruments synchronous step down DC voltage controller gives you the ability to do just that. Its output produces a current of 15Max A. With an output that has a voltage of 0.76 to 5.5 V, this is power management at its best. This DC voltage controller has 2 outputs. This DC voltage controller has an input voltage of 4.5 to 24 V. It has a switching frequency of 350|700 kHz. In order to ensure parts aren"t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. This DC voltage controller has a minimum operating temperature of -40 °C and a maximum of 85 °C.
频率 700 kHz
电源电压DC 4.50V min
输出接口数 2
输出电压 0.76V ~ 5.5V
输出电流 15 A
针脚数 24
耗散功率 778 mW
静态电流 450 µA
调节输出数 2
开关频率 700 kHz
过温保护 Yes
拓扑结构 Buck
占空比 89 %
输入电压Max 24 V
输入电压Min 4.5 V
输出电流Max 15 A
工作温度Max 85 ℃
工作温度Min -40 ℃
耗散功率Max 778 mW
电源电压 4.5V ~ 24V
电源电压Max 24 V
电源电压Min 4.5 V
输入电压 4.5V ~ 24V
安装方式 Surface Mount
引脚数 24
封装 TSSOP-24
封装 TSSOP-24
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Cut Tape CT
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/06/15
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
TPS53126PW TI 德州仪器 | 当前型号 | 当前型号 |
TPS53126PWR 德州仪器 | 类似代替 | TPS53126PW和TPS53126PWR的区别 |
