KEMET T520V227M004ATE018 表面贴装钽电容, 220 µF, 4 V, KO-CAP T520 Series, 2917 [7343 公制], -55 °C 新
T520 Series — Conductive Polymer Chip Capacitor
**Features:**
* Capacitance Range: 15 μF to 1000 μF
* Voltage Rating: 2 VDC to 25 VDC**
* **Kemet Organic Capacitor KO-CAP**
**
* Low ESR and Improved CAP Retention at High Frequency**
**
* Ta Anode and Ta2O5 Dielectric**
**
* A Conductive, Organic Polymer Replaces the MnO2 as the Cathode Plate of the Capacitor**
**
* Exhibits a Benign Failure Rate**
**
* Offers a More Cost-Effective Solution to High-Cost High-Cap Ceramic Capacitors
额定电压DC 4 V
电容 220 µF
等效串联电阻ESR 0.018 Ω
容差 ±20 %
产品系列 T520
纹波电流 3200 mA
工作温度Max 105 ℃
工作温度Min -55 ℃
额定电压 4 V
安装方式 Surface Mount
引脚数 2
封装 7343
长度 7.3 mm
宽度 4.3 mm
高度 1.8 mm
封装 7343
介质材料 Tantalum
工作温度 -55℃ ~ 105℃
包装方式 Cut Tape CT
最小包装 1000
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2016/06/20
ECCN代码 EAR99
