TPS7A3301RGWR

â ???? 36 - V，A ???? 1 -A ，超低噪音负电压稳压器 –36-V, –1-A, Ultralow-Noise Negative Voltage Regulator

DESCRIPON

The TPS7A33 series of linear regulators are negative voltage –36 V, ultralow-noise 16 μVRMS, 72 dB PSRR linear regulators capable of sourcing a maximum load of 1 A.

FEATURES

• Input Voltage Range: –3 V to –36 V

• Noise:

  – 16 μVRMS10 Hz to 100 kHz

• Power-Supply Ripple Rejection:

  – 72 dB 10 kHz

• Adjustable Output: –1.18 V to –33 V

• Maximum Output Current: 1 A

• Stable with Ceramic Capacitors ≥ 10 μF

• Built-In Current-Limit and Thermal Shutdown Protection

• Available in an External Heatsink-Capable, High Thermal Performance TO-220 Package

• Operating Temperature Range: –40°C to +125°C

APPLICATIONS

• Supply Rails for Op Amps, DACs, ADCs, and Other High-Precision Analog Circuitry

• Audio

• Post DC/DC Converter Regulation and Ripple Filtering

• Test and Measurement

• Medical

• Industrial Instrumentation

• Base Stations and Telecom Infrastructure

• 12-V and 24-V Industrial Buses
