TPS75718KC

1.8V,3A带输出电压检测的极低压差稳压器

PMIC - 稳压器 - 线性 正 固定 输出 3A TO-220-5

得捷:
IC REG LINEAR 1.8V 3A TO220-5

立创商城:
TPS75718KC

德州仪器TI:
3-A, ultra-low-dropout voltage regulator with power good & enable

艾睿:
If you need to maintain a steady voltage on your circuit, then this LDO TPS75718KC linear regulator from Texas Instruments is perfect for you! It has an overall accuracy of ±3 %. Its typical dropout voltage at current is 0.15@3A V. This voltage regulation device&s;s single output can produce a current up to 3 A. With a small input voltage of 2.8 V and a max of 5.5 V, this will supply sufficient power to your circuit. With a fixed output that has a voltage of 1.8 V, this is power management at its best. Users like the load regulation of 0.35%/VTyp and line regulation of 0.04%/VTyp. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. Its polarity is positive. This voltage regulation device has a minimum operating temperature of -40 °C and a maximum of 125 °C.

安富利:
LDO Regulator Pos 1.8V 3A 5-Pin5+Tab TO-220 Tube

Chip1Stop:
Single Channel LDO Single Output LDO, 3.0A, Fixed1.8V, Fast Transient Response, Low Quiescent Current LDO Regulator Pos 1.8V 3A 5-Pin5+Tab TO-220 Tube

Verical:
LDO Regulator Pos 1.8V 3A 5-Pin5+Tab TO-220 Tube

力源芯城:
1.8V,3A带输出电压检测的极低压差稳压器

Win Source:
Linear Voltage Regulator IC Positive Fixed 1 Output 1.8V 3A TO-220-5
