TPS73632MDBVREP

具有反向电流保护无电容NMOS 400毫安低压差稳压器 CAP-FREE NMOS 400 mA LOW-DROPOUT REGULATORS WITH REVERSE CURRENT PROTECTION

PMIC - 稳压器 - 线性 正 固定 输出 400mA SOT-23-5

立创商城:
TPS73632MDBVREP

德州仪器TI:
Enhanced product, cap-free NMOS, 400-mA low-dropout regulator with reverse current protection

得捷:
IC REG LINEAR 3.2V 400MA SOT23-5

贸泽:
LDO Voltage Regulators Mil Enh Cap-Free NMOS 400-mA LDO Reg

艾睿:
This LDO TPS73632MDBVREP linear regulator from Texas Instruments gives you control over the voltage levels of your circuit. It has an overall accuracy of ±0.5 %. Its typical dropout voltage at current is 0.075@400mA V. This device has a maximum power dissipation of 556 mW. This voltage regulation device&s;s single output can produce a current up to 0.4 A. Using the part will provide the power your application needs by requiring a voltage only of 1.7 V and not exceeding a voltage of 5.5 V. With a fixed output that has a voltage of 3.2 V, this is power management at its best. Users like the load regulation of 0.002%/mATyp and line regulation of 0.01%/VTyp. Its maximum power dissipation is 556 mW. This product will be shipped in tape and reel packaging so that components can be mounted effectively. Its polarity is positive. The maximum dropout voltage is 0.2@400mA V. This voltage regulation device has a minimum operating temperature of -55 °C and a maximum of 125 °C.

安富利:
LDO Regulator Pos 3.2V 0.4A 5-Pin SOT-23 T/R
