TVX1V332MCD

Cap Aluminum Lytic 3300uF 35V 20% 16 X 41.5mm Axial 2050mA 2000H 85℃

铝电解器 轴向，CAN - 85°C 时为 2000 小时

得捷:
CAP ALUM 3300UF 20% 35V AXIAL

贸泽:
Aluminum Electrolytic Capacitors - Leaded 35volts 3300uF 16x41.5 20%

艾睿:
Using the aluminum anode based electrolytic TVX1V332MCD electrolytic capacitor, developed by Nichicon, you can filter out lower signal frequencies. It can withstand a voltage of 35 VDC. This aluminum electrolytic capacitor has a maximum operating temperature of 85 °C. Its capacitance value is 3300uF. The TVX1V332MCD aluminum electrolytic capacitor has an axial termination style. Its leakage current is 4@1Min|3@2Min μA. This part has a lead diameter of 0.8 mm. This product is 41.5 mm long with a diameter of 16 mm. It has a tolerance of 20%.

安富利:
Cap Aluminum 3300uF 35V 20% 16 X 41.5mm Axial 2050mA 2000 hr 85°C

Chip1Stop:
Cap Aluminum Lytic 3300uF 35V 20% 16 X 41.5mm Axial 2050mA 2000h 85℃

TME:
Capacitor: electrolytic; THT; 3300uF; 35VDC; Ø16x41.5mm; ±20%

Newark:
Electrolytic Capacitor, General Purpose, 3300 µF, 35 V, VX Series, ± 20%, Axial Leaded, 16 mm
