锁扣, D型, 漏极开路, 150 ns, SOIC
Think of Texas Instruments" flip flop device in the event you need to save or retrieve your circuit"s state information quickly. With an open drain output, this is power management at its best. It has a single-ended output signal. This flip flop has an operating temperature range of -40 °C to 125 °C. This device comes in tube packaging. It has 8 channels per chip. This inverting device has a typical operating supply voltage of 5 V. Its minimum operating supply voltage of 4.5 V, while its maximum is 5.5 V.
电源电压DC 4.50V min
输出接口数 8
输出电流 500 mA
电路数 1
针脚数 20
位数 8
输入数 8
工作温度Max 125 ℃
工作温度Min -40 ℃
电源电压 4.5V ~ 5.5V
电源电压Max 5.5 V
电源电压Min 4.5 V
安装方式 Surface Mount
引脚数 20
封装 SOIC-20
长度 12.8 mm
宽度 7.52 mm
高度 2.35 mm
封装 SOIC-20
工作温度 -40℃ ~ 125℃
产品生命周期 Active
包装方式 Tube
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/06/15
ECCN代码 EAR99
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
TPIC6B273DWG4 TI 德州仪器 | 当前型号 | 当前型号 |
TPIC6B273DW 德州仪器 | 完全替代 | TPIC6B273DWG4和TPIC6B273DW的区别 |
TPIC6B273DWRG4 德州仪器 | 完全替代 | TPIC6B273DWG4和TPIC6B273DWRG4的区别 |
TPIC6B273N 德州仪器 | 类似代替 | TPIC6B273DWG4和TPIC6B273N的区别 |
