Texas Instruments### 功率逻辑
功率逻辑,Texas Instruments
得捷:
IC 8-BIT ADDRESSABL LTCH 24SOIC
立创商城:
TPIC6A259DW
德州仪器TI:
8-bit addressable latch with 350mA/ch
欧时:
### 功率逻辑,Texas Instruments### 功率逻辑
艾睿:
This d-type TPIC6A259DW low-level latch manufactured by Texas Instruments contains real time information and can be pushed through it once it is enabled. With an open drain output, this is power management at its best. This latch has an operating temperature range of -40 °C to 125 °C. This device comes in tube packaging. It has 8 channels per chip. This non-inverting device has a typical operating supply voltage of 5 V. Its minimum operating supply voltage of 4.5 V, while its maximum is 5.5 V.
安富利:
Latch Addressable Open Drain 8-CH D-Type 24-Pin SOIC Tube
Chip1Stop:
Latch Addressable Open Drain 8-CH D-Type 24-Pin SOIC Tube
Verical:
Latch Addressable Open Drain 8-CH D-Type Automotive 24-Pin SOIC Tube
Newark:
# TEXAS INSTRUMENTS TPIC6A259DW Latch, Addressable, Open Drain, 125 ns, 600 mA, SOIC
电源电压DC 4.50V min
输出接口数 8
输出电压 ≤50.0 V
输出电流 600 mA
电路数 1
位数 8
输入数 1
工作温度Max 125 ℃
工作温度Min -40 ℃
电源电压 4.5V ~ 5.5V
电源电压Max 5.5 V
电源电压Min 4.5 V
安装方式 Surface Mount
引脚数 24
封装 SOIC-24
长度 15.4 mm
宽度 7.52 mm
高度 2.35 mm
封装 SOIC-24
工作温度 -40℃ ~ 125℃
产品生命周期 Active
包装方式 Tube
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/06/15
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
TPIC6A259DW TI 德州仪器 | 当前型号 | 当前型号 |
TPIC6A259DWG4 德州仪器 | 完全替代 | TPIC6A259DW和TPIC6A259DWG4的区别 |
TPIC6A259DWRG4 德州仪器 | 完全替代 | TPIC6A259DW和TPIC6A259DWRG4的区别 |
TPIC6A259DWR 德州仪器 | 类似代替 | TPIC6A259DW和TPIC6A259DWR的区别 |
