TMC429-PI24

TRINAMIC  TMC429-PI24  芯片, 步进电机控制器, SOP24

The is a miniaturized Stepper Motor Controller with an industry leading feature set. It controls up to three motors via SPI or step/direction interface. The SPI interface provides a programmable 6-bit microstep table 64µsteps/full step for best step accuracy with 2-phase stepper motors. Based on target positions and velocities - which can be altered on the fly - it performs all real time critical tasks autonomously. The TMC429 offers high level control functions for robust and reliable operation. Two separate 4 wire serial peripheral interfaces allow for communication with the microcontroller and with up to three daisy chained stepper motor drivers. Together with a microcontroller the TMC429 forms a complete motion control system. High integration and small form factor allow for miniaturized designs for highly competitive solutions.

.

Controls up to three stepper motors

.

Serial 4-wire interface for µC with easy-to-use protocol

.

Interface for SPI™ motor drivers with data rates up to 1Mbps

.

Step/direction interface

.

Internal position counters 24-bit wide

.

Microstep frequency up to 1MHz

.

Read-out option for all motion parameters

.

Programmable 6 bit microstep table, up to 64 entries for a quarter sine wave period

.

Ramp generators for autonomous positioning/speed control

.

On-the-fly change of target motion parameters

.

Power boost automatic acceleration dependent current control

.

Up to 32MHz can use CPU clock Clock frequency

.

1.25mA at 4MHz Typical low power operation
