TEXAS INSTRUMENTS TRF37C75IDSGT 芯片, 射频放大器, 18DB, 4GHZ, WSON-8
The TRF37C75 is packaged in a 2.00mm × 2.00mm WSON with a power down pin making it ideal for applications where space and low power modes are critical.
The TRF37C75 is designed for ease of use. For maximum flexibility, this family of parts uses a common 5 V supply and consumes 85 mA. In addition, this family was designed with an active bias circuit that provides a stable and predictable bias current over process, temperature and voltage variations. For gain and linearity budgets the device was designed to provide a flat gain response and excellent OIP3 out to 4000 MHz. For space constrained applications this family is internally matched to 50 Ω which simplifies ease of use and minimizes needed PCB area.
频率 40MHz ~ 4GHz
电源电压DC 4.50V min
供电电流 85 mA
通道数 1
针脚数 8
耗散功率 425 mW
输出功率 18 dBm
增益 18 dB
测试频率 2 GHz
工作温度Max 85 ℃
工作温度Min -40 ℃
耗散功率Max 425 mW
电源电压 4.5V ~ 5.25V
电源电压Max 5.25 V
电源电压Min 4.5 V
引脚数 8
封装 WSON-8
封装 WSON-8
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Cut Tape CT
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/06/15
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
TRF37C75IDSGT TI 德州仪器 | 当前型号 | 当前型号 |
TRF37C75IDSGR 德州仪器 | 功能相似 | TRF37C75IDSGT和TRF37C75IDSGR的区别 |
