TR-61822概述

MACROMATIC CONTROLS  TR-61822  延时继电器, DPDT

Input voltage must first be applied. Upon application of the trigger voltage, the relay contacts transfer and hold. At the end of the preset time, the relay contacts return to their normal condition unless the trigger voltage is removed and reapplied before the preset time elapses. Continuous cycling of the trigger voltage at a rate faster than the preset time will cause the relay contacts to remain closed.
.
*Features:**

* 16 Timing Ranges in a Single Timer

* Covers 0.1 S to 2 H 0.6 S to 24 H on TR-631, TR-651 and TR-661 Units and 0.1 S to 30 M on TR-606 Units

* User Selects Desired Time Range by Setting a Rotary Switch — No Math Required or DIP Switches to Set

* Adjust within Selected Range Using Potentiometer

* Standard 8- or 11-Pin Octal Socket Mounting

* All Units Operate on Both AC and DC

* Repeat Cycle and Delayed Interval Units Have Independently Selectable and Adjustable ON and OFF Times **Specifications:**

* DPDT 10 A @ 240 VAC/30 VDC

* 0.1% Repeat Accuracy

* Temperature: –28° to +65°C

* Dimensions: 1.7" × 2.4" × 3.5"

TR-61822中文资料参数规格
技术参数

额定电流 10 A

额定功率 2 VA

触点类型 DPDT

载流 10.0 A

输入电压 120 V

封装参数

安装方式 Plug In

引脚数 11

物理参数

工作温度 -28℃ ~ 65℃

符合标准

RoHS标准 RoHS Compliant

数据手册

在线购买TR-61822
型号: TR-61822
制造商: Macromatic Controls
描述:MACROMATIC CONTROLS  TR-61822  延时继电器, DPDT
