TC164-FR-07100KL

YAGEO PHYCOMP  TC164-FR-07100KL  电阻阵列, ARC242 1206 100K

器网络与阵列

得捷:
RES ARRAY 4 RES 100K OHM 1206

立创商城:
100kΩ ±1%

艾睿:
Conserve space and power by adopting this TC164-FR-07100KL resistor array from Yageo, allowing multiple configurations of resistors to be downsized into an IC. This product&s;s 4 resistors have a value of 100K Ohm. Its temperature coefficient is ±200 ppm/°C. This dependable part has a power rating per resistor of 0.063 1/16 W. It has 8 terminals. This product will be shipped in tape and reel packaging so that components can be mounted effectively. The TC164-FR-07100KL part has a concave termination style. It has a tolerance of 1%. This product&s;s terminal pitch is 0.8 mm. This product is 3.2 mm long, 0.6 mm tall and 1.6 mm deep. This part has an operating temperature of -55 to 155 °C. This device is made with thick film technology.

Chip1Stop:
Res Thick Film Array 100K Ohm 1% ﾂｱ200ppm/C ISOL Epoxy 8-Pin 12064 X 0603 Concave SMD T/R

Verical:
Res Thick Film Array 100K Ohm 1% ±200ppm/C ISOL Epoxy 8-Pin 12064 X 0603 Concave SMD Automotive T/R

Newark:
RESISTOR ARRAY, ARC242 1206 100K

儒卓力:
**CN1206R4 100K 1% 0,063W CONCAV **
