TPS7H1201SHKS

具有软启动和电源正常指示功能的极低压降稳压器 16-CFP -55 to 210

Linear Voltage Regulator IC Positive Adjustable 1 Output 500mA 16-CFP

得捷:
IC REG LIN POS ADJ 500MA 16CFP

德州仪器TI:
Very Low Dropout Regulator With SoftStart and Powergood

艾睿:
Never worry about components not turning off and on due to lack of voltage with this LDO TPS7H1201SHKS linear regulator from Texas Instruments. Its typical dropout voltage at current is 0.0555@0.5A V. It has an overall accuracy of ±2 %. This voltage regulation device&s;s single output can produce a current up to 0.5 A. This will operate at a minimum voltage of 1.5 V and a maximum voltage of 7 V, making it easy to control the power in your circuit. With an adjustable output that has a voltage of 0.8 to 6.8 V, this is power management at its best. Your circuit has the capability to produce a constant current at its output by using a load regulation of 0.00825%/ATyp and line regulation of 0.01%/VTyp. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. The maximum dropout voltage is 0.1@0.5A V. This voltage regulation device has a minimum operating temperature of -55 °C and a maximum of 210 °C. Its polarity is positive.

安富利:
LDO Regulator Pos 1.2V to 6.8V 0.5A 16-Pin CFP T/R

Verical:
LDO Regulator Pos 0.8V to 6.8V 0.5A 16-Pin CFPAK Tube
