TC1044SMJA

电荷泵DC - DC电压转换器 Charge Pump DC-TO-DC Voltage Converter

GENERAL DESCRIPTION

The TC1044S is a pin-compatible upgrade to the Industry standard TC7660 charge pump voltage converter. It converts a +1.5V to +12V input to a corresponding –1.5V to –12V output using only two low cost capacitors, eliminating inductors and their associated cost, size and EMI. Added features include an extended supply range to 12V, and a frequency boost pin for higher operating frequency,

allowing the use of smaller external capacitors.

得捷:
IC REG CHARG PUMP INV 8CERDIP

艾睿:
Charge Pump INV -12V to -1.5V Automotive 8-Pin CDIP Tube
