TMM-114-01-G-S

2mm 方针

针座 通孔 14 位置 0.079"（2.00mm）

得捷:
CONN HEADER VERT 14POS 2MM

欧时:
HEADER TH 14POS 2MM

立创商城:
2mm 方针

艾睿:
Think of Samtec&s;s unshrouded TMM-114-01-G-S header connector the next time you&s;re concerned about accidentally shorting out pins on your printed circuit. This HDR connector&s;s 14 contacts that are made out of phosphor bronze and plated with gold over nickel. Its pitch is 2 mm. It has a straight body orientation. It has a header type gender. This is a 1-row connector. It has a maximum voltage rating of 500 VAC. This device has a maximum current rating of 5.5 A/contact. This product comes packaged in bulk, so the parts will be stored loosely. TMM-114-01-G-S is housed in black liquid crystal polymer. This connector has an operating temperature of -55 to 125 °C. This product is 28 mm long, 4.7 mm tall and 1.97 mm deep. It uses the solder termination method.

安富利:
Conn Unshrouded Header HDR 14 POS 2mm Solder ST Thru-Hole
