TL7705AIPG4

TEXAS INSTRUMENTS  TL7705AIPG4  监控器单电源, 高电平有效, 低电平有效复位, 3.5V-18V输入, DIP-8

The is a single-supply Voltage Supervisor for 5V systems with programmable time delay. The integrated-circuit supply-voltage supervisor designed specifically for use as reset controllers in microcomputer and microprocessor systems. The supply-voltage supervisor monitors the supply for under-voltage conditions at the SENSE input. During power up, the /RESET output becomes active low when VCC attains a value approaching 3.6V. At this point assuming that SENSE is above VIT+, the delay timer function activates a time delay, after which outputs /RESET and RESET go inactive high and low, respectively. When an under-voltage condition occurs during normal operation, /RESET and RESET go active.

.

power-ON reset generator

.

Automatic reset generation after voltage drop

.

Wide supply-voltage range

.

Precision voltage sensor

.

Temperature-compensated voltage reference

.

Externally adjustable pulse duration
