TSW-115-07-S-D

Conn Unshrouded Header HDR 30POS 2.54mm Solder ST Thru-Hole

针座 通孔 30 位置 0.100"（2.54mm）

得捷:
CONN HEADER VERT 30POS 2.54MM

艾睿:
Mounting this unshrouded TSW-115-07-S-D header connector from Samtec to your printed circuit board can help you support multiple physical configuration options. This HDR connector&s;s 30 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a maximum voltage rating of 550 VAC. This is a 2-row connector. It has a straight body orientation. Its pitch is 2.54 mm. It has a header type gender. This device has a maximum current rating of 6.3 A/contact. This product comes packaged in bulk, so the parts will be stored loosely. TSW-115-07-S-D is housed in black polyester. This connector has an operating temperature of -55 to 125 °C. It uses the solder termination method. This product is 38.1 mm long, 8.38 mm tall and 5.08 mm deep.

Online Components:
Conn Unshrouded Header HDR 30 POS 2.54mm Solder ST Thru-Hole Bulk

Electro Sonic:
Conn Unshrouded Header HDR 30 POS 2.54mm Solder ST Thru-Hole Bulk
