TMM-125-01-S-D-SM

CONN HEADER 50POS DUAL 2MM SMD

Connector Header Surface Mount 50 position 0.079" 2.00mm

得捷:
CONN HEADER SMD 50POS 2MM

艾睿:
Reduce safety concerns with this unshrouded TMM-125-01-S-D-SM header connector from Samtec which will reduce the possibility of accidentally shorting pins when a printed circuit board is being used. This HDR connector&s;s 50 contacts that are made out of phosphor bronze and plated with gold over nickel. Its pitch is 2 mm. It has a header type gender. This is a 2-row connector. It has a maximum voltage rating of 500 VAC. It has a straight body orientation. This device has a maximum current rating of 3.2 A/contact. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. It uses the solder termination method. TMM-125-01-S-D-SM is housed in black liquid crystal polymer. This product is 50 mm long, 5.97 mm tall and 7.06 mm deep. This connector has an operating temperature of -55 to 125 °C.

安富利:
Conn Unshrouded Header HDR 50 POS 2mm Solder ST SMD Tube
