TSW-108-25-T-S-RA

2.54mm 方针

针座 通孔，直角 8 位置 0.100"（2.54mm）

得捷:
CONN HEADER 8POS .100" SNGL R/A

欧时:
Classic PCB HDR Strips 0.100"

立创商城:
2.54mm 方针

艾睿:
As an added safety precaution, the unshrouded TSW-108-25-T-S-RA header connector from Samtec will prevent and protect components on your circuit board from accidentally touching each other. This HDR connector&s;s 8 contacts that are made out of phosphor bronze and plated with tin over nickel. Its pitch is 2.54 mm. It has a maximum voltage rating of 450 VAC. It has a header type gender. It has a right angle body orientation. This is a 1-row connector. This device has a maximum current rating of 6.3 A/contact. This product comes packaged in bulk, so the parts will be stored loosely. This connector has an operating temperature of -55 to 105 °C. It uses the solder termination method. This product is 20.32 mm long, 3.02 mm tall and 12.19 mm deep. TSW-108-25-T-S-RA is housed in black polyester.

安富利:
Conn Unshrouded Header HDR 8 POS 2.54mm Solder RA Thru-Hole

Chip1Stop:
Conn Unshrouded Header HDR 8 POS 2.54mm Solder RA Thru-Hole Bulk

Newark:
# SAMTEC  TSW-108-25-T-S-RA  Board-To-Board Connector, 2.54 mm, 8 Contacts, Header, TSW Series, Through Hole, 1 Rows
