TSW-106-17-G-S

SAMTEC TSW-106-17G-S Board-To-Board Connector, 2.54mm, 6Contacts, Header, TSW Series, Through Hole, 1Rows

针座 通孔 6 位置 0.100"（2.54mm）

得捷:
CONN HEADER VERT 6POS 2.54MM

欧时:
Classic PCB HDR Strips 0.100"

艾睿:
Safety is an important concern when designing electronic devices. Samtec&s;s unshrouded TSW-106-17-G-S header connector helps protect your equipment from accidental shortages. This HDR connector&s;s 6 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a straight body orientation. It has a maximum voltage rating of 550 VAC. It has a header type gender. This is a 1-row connector. Its pitch is 2.54 mm. This device has a maximum current rating of 6.3 A/contact. This product comes packaged in bulk, so the parts will be stored loosely. This product is 15.24 mm long, 18.28 mm tall and 2.54 mm deep. TSW-106-17-G-S is housed in black polyester. It uses the solder termination method. This connector has an operating temperature of -55 to 125 °C.

安富利:
Conn Unshrouded Header HDR 6 POS 2.54mm Solder ST Thru-Hole

Verical:
Conn Unshrouded Header HDR 6 POS 2.54mm Solder ST Top Entry Thru-Hole Bulk

Newark:
# SAMTEC  TSW-106-17-G-S  Board-To-Board Connector, 2.54 mm, 6 Contacts, Header, TSW Series, Through Hole, 1 Rows

Electro Sonic:
Conn Unshrouded Header HDR 6 POS 2.54mm Solder ST Thru-Hole Bulk
