TSW-106-09-G-S-RA

SAMTEC TSW-106-09-G-S-RA Board-To-Board Connector, 2.54mm, 6Contacts, Header, TSW Series, Through Hole, 1Rows

针座 通孔，直角 6 位置 0.100"（2.54mm）

得捷:
CONN HEADER R/A 6POS 2.54MM

艾睿:
Look no further than the unshrouded TSW-106-09-G-S-RA header connector from Samtec, a great tool to use when board-to-board interconnects is required. This HDR connector&s;s 6 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a header type gender. Its pitch is 2.54 mm. It has a right angle body orientation. It has a maximum voltage rating of 450 VAC. This is a 1-row connector. This device has a maximum current rating of 6.3 A/contact. This product comes packaged in bulk, so the parts will be stored loosely. This connector has an operating temperature of -55 to 125 °C. It uses the solder termination method. This product is 15.24 mm long, 3.02 mm tall and 9.9 mm deep. TSW-106-09-G-S-RA is housed in black polyester.

安富利:
Conn Unshrouded Header HDR 6 POS 2.54mm Solder RA Thru-Hole

Newark:
# SAMTEC  TSW-106-09-G-S-RA  Board-To-Board Connector, 2.54 mm, 6 Contacts, Header, TSW Series, Through Hole, 1 Rows
