TSW-105-22-G-S-RA

SAMTEC TSW-105-22G-S-RA Board-To-Board Connector, 2.54mm, 5Contacts, Header, TSW Series, Through Hole, 1Rows

针座 通孔，直角 5 位置 0.100"（2.54mm）

得捷:
CONN HEADER R/A 5POS 2.54MM

欧时:
HEADER R/A 5POS 2.54MM 1 ROW

艾睿:
Safety is an important concern when designing electronic devices. Samtec&s;s unshrouded TSW-105-22-G-S-RA header connector helps protect your equipment from accidental shortages. This HDR connector&s;s 5 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a right angle body orientation. This is a 1-row connector. It has a header type gender. It has a maximum voltage rating of 450 VAC. Its pitch is 2.54 mm. This device has a maximum current rating of 6.3 A/contact. TSW-105-22-G-S-RA is housed in black polyester. This connector has an operating temperature of -55 to 125 °C. It uses the solder termination method. This product is 12.7 mm long, 3.02 mm tall and 9.9 mm deep.

Verical:
Conn Unshrouded Header HDR 5 POS 2.54mm Solder RA Side Entry Thru-Hole Bulk

Newark:
# SAMTEC  TSW-105-22-G-S-RA  Board-To-Board Connector, 2.54 mm, 5 Contacts, Header, TSW Series, Through Hole, 1 Rows
