TSW-104-26-F-D

SAMTEC TSW-104-26F-D Board-To-Board Connector, 2.54mm, 8Contacts, Header, TSW Series, Through Hole, 2Rows

针座 通孔 8 位置 0.100"（2.54mm）

得捷:
CONN HEADER VERT 8POS 2.54MM

艾睿:
Look no further than the unshrouded TSW-104-26-F-D header connector from Samtec, a great tool to use when board-to-board interconnects is required. This HDR connector&s;s 8 contacts that are made out of phosphor bronze and plated with gold over nickel. This is a 2-row connector. It has a maximum voltage rating of 550 VAC. It has a header type gender. Its pitch is 2.54 mm. It has a straight body orientation. This device has a maximum current rating of 6.3 A/contact. This product is 10.16 mm long, 8.38 mm tall and 5.08 mm deep. It uses the solder termination method. TSW-104-26-F-D is housed in black polyester. This connector has an operating temperature of -55 to 125 °C.

安富利:
Conn Unshrouded Header HDR 8 POS 2.54mm Solder ST Thru-Hole

Newark:
# SAMTEC  TSW-104-26-F-D  Board-To-Board Connector, 2.54 mm, 8 Contacts, Header, TSW Series, Through Hole, 2 Rows
