TSW-103-14-F-D

SAMTEC TSW-103-14F-D Board-To-Board Connector, 2.54mm, 6Contacts, Header, TSW Series, Through Hole, 2Rows

针座 通孔 6 位置 0.100"（2.54mm）

欧时:
Classic PCB HDR Strips 0.100"

得捷:
CONN HEADER VERT 6POS 2.54MM

艾睿:
Use this unshrouded TSW-103-14-F-D connector from Samtec when board-to-board interconnects is required. This HDR connector&s;s 6 contacts that are made out of phosphor bronze and plated with gold over nickel. This is a 2-row connector. It has a straight body orientation. It has a header type gender. It has a maximum voltage rating of 550 VAC. Its pitch is 2.54 mm. This device has a maximum current rating of 6.3 A/contact. It uses the solder termination method. TSW-103-14-F-D is housed in black polyester. This connector has an operating temperature of -55 to 125 °C. This product is 7.62 mm long, 10.67 mm tall and 5.08 mm deep.

安富利:
Conn Unshrouded Header HDR 6 POS 2.54mm Solder ST Thru-Hole

Newark:
# SAMTEC  TSW-103-14-F-D  Board-To-Board Connector, 2.54 mm, 6 Contacts, Header, TSW Series, Through Hole, 2 Rows
