TSW-103-07-F-T

2.54mm 方针

针座 通孔 9 位置 0.100"（2.54mm）

得捷:
CONN HEADER VERT 9POS 2.54MM

立创商城:
2.54mm 方针

艾睿:
This unshrouded TSW-103-07-F-T header connector from Samtec is used for jumper posts to support physical configuration options on printed circuit boards. This HDR connector&s;s 9 contacts that are made out of phosphor bronze and plated with gold over nickel. Its pitch is 2.54 mm. It has a maximum voltage rating of 550 VAC. This is a 3-row connector. It has a straight body orientation. It has a header type gender. This device has a maximum current rating of 6.3 A/contact. This product comes packaged in bulk, so the parts will be stored loosely. This product is 7.62 mm long, 8.38 mm tall and 7.62 mm deep. It uses the solder termination method. This connector has an operating temperature of -55 to 125 °C. TSW-103-07-F-T is housed in black polyester.

Newark:
# SAMTEC  TSW-103-07-F-T  Board-To-Board Connector, 2.54 mm, 9 Contacts, Header, TSW Series, Through Hole, 3 Rows
