TMS-105-02-G-S

SAMTEC TMS-105-02-G-S Board-To-Board Connector, 1.27mm, 5Contacts, Header, TMS Series, Through Hole, 1Rows

针座 通孔 5 位置 0.050"（1.27mm）

得捷:
CONN HEADER 5POS .050" T/H GOLD

欧时:
.050" x .100" Micro Terminal Strip

艾睿:
This unshrouded TMS-105-02-G-S header connector from Samtec is used for jumper posts to support physical configuration options on printed circuit boards. This HDR connector&s;s 5 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a header type gender. Its pitch is 1.27 mm. This is a 1-row connector. It has a straight body orientation. This device has a maximum current rating of 5 A/contact. This product comes packaged in bulk, so the parts will be stored loosely. This connector has an operating temperature of -55 to 125 °C. This product is 6.35 mm long, 5.08 mm tall and 2.48 mm deep. It uses the solder termination method. TMS-105-02-G-S is housed in black liquid crystal polymer.

安富利:
Conn Unshrouded Header HDR 5 POS 1.27mm Solder ST Thru-Hole

Verical:
Conn Unshrouded Header HDR 5 POS 1.27mm Solder ST Top Entry Thru-Hole Bulk

Newark:
# SAMTEC  TMS-105-02-G-S  Board-To-Board Connector, 1.27 mm, 5 Contacts, Header, TMS Series, Through Hole, 1 Rows
