TMM-107-01-T-S-SM

SAMTEC TMM-107-01-T-S-SM Board-To-Board Connector, 2mm, 7Contacts, Header, TMM Series, Surface Mount, 1Rows

针座 表面贴装型 7 位置 0.079"（2.00mm）

得捷:
CONN HEADER SMD 7POS 2MM

艾睿:
Use this unshrouded TMM-107-01-T-S-SM header connector from Samtec where IDC ribbon cables are used. This HDR connector&s;s 7 contacts that are made out of phosphor bronze and plated with matte tin over nickel. Its pitch is 2 mm. It has a straight body orientation. This is a 1-row connector. It has a header type gender. It has a maximum voltage rating of 500 VAC. This device has a maximum current rating of 3.2 A/contact. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. This connector has an operating temperature of -55 to 105 °C. It uses the solder termination method. TMM-107-01-T-S-SM is housed in black liquid crystal polymer. This product is 14 mm long, 5.97 mm tall and 4.83 mm deep.

安富利:
Conn Unshrouded Header HDR 7 POS 2mm Solder ST SMD Tube

Newark:
# SAMTEC  TMM-107-01-T-S-SM  Board-To-Board Connector, 2 mm, 7 Contacts, Header, TMM Series, Surface Mount, 1 Rows
