TEP 200-2415WIRCMF概述

Traco 180-240W Chassis Mount Railway Compliant DC-DC Converter - TEP-200WIR Ser180-240W single output isolated PCB mount DC-DC converters with a wide 4:1 input voltage range, adjustable output voltage and a high efficiency of up to 91% allowing full power operation without forced air cooling at 25°C. These railway compliant isolated DC-DC converters are chassis mount with a screw terminal block and have an integrated EMI filter to meet EN 55022 class A.Wide 4:1 input voltage range Integrated EMI filter to EN 55022, class A Adjustable output voltage EN 50155 approval for railway applications High efficiency No minumum load Soft start Sense line Remote On/Off input Reverse input voltage, overtemperature, short circuit and over voltage protection EMC compliance: EN 55022 class A without external components ### 注A DIN rail mounting kit is available, see stock number 745-1102 MTBF to MIL-HDBK-217F, at +25°C Derating approx. 1.2 %/K above +25°C see datasheet### 标准EN 50155, UL 60950-1, IEC/EN 60950-1### Traco - 75W 至 240W - TEP 系列

Traco 180-240W Chassis Mount Railway Compliant DC-DC Converter - TEP-200WIR Ser

180-240W single output isolated PCB mount DC-DC converters with a wide 4:1 input voltage range, adjustable output voltage and a high efficiency of up to 91% allowing full power operation without forced air cooling at 25°C. These railway compliant isolated DC-DC converters are chassis mount with a screw terminal block and have an integrated EMI filter to meet EN 55022 class A.

Wide 4:1 input voltage range

Integrated EMI filter to EN 55022, class A

Adjustable output voltage

EN 50155 approval for railway applications

High efficiency

No minumum load

Soft start

Sense line

Remote On/Off input

Reverse input voltage, overtemperature, short circuit and over voltage protection

EMC compliance: EN 55022 class A without external components

### 注

A DIN rail mounting kit is available, see stock number 745-1102

MTBF to MIL-HDBK-217F, at +25°C

Derating approx. 1.2 %/K above +25°C see datasheet

### 标准

EN 50155, UL 60950-1, IEC/EN 60950-1

### Traco - 75W 至 240W - TEP 系列

TEP 200-2415WIRCMF中文资料参数规格

技术参数

额定功率 180 W

输出接口数 1

输出电压 24 VDC

输出电流 7.5 A

输出功率 180 W

隔离电压 2.25 kVDC

输入电压Max 36 V

输入电压Min 9 V

输入电压DC Max 36 V

输入电压DC Min 8.5 v

输出电流Max 7.5 A

输出功率Max 180 W

输入电压 24 VDC

封装参数

安装方式 Chassis

外形尺寸

长度 85 mm

宽度 61 mm

高度 33.8 mm

物理参数

重量 240 g

工作温度 40℃ ~ 75℃

其他

产品生命周期 Active

包装方式 Bulk

制造应用 Industrial, 通信与网络, 电源管理, 工业, ITE（商业），铁路, 自动化与过程控制, Automation & Process Control, Communications & Networking, Power Management

符合标准

RoHS标准 RoHS Compliant

含铅标准无铅

REACH SVHC标准 No SVHC

REACH SVHC版本 2015/12/17
