TSW-108-07-F-D

SAMTEC TSW-108-07-F-D Board-To-Board Connector, 2.54mm, 16Contacts, Header, TSW Series, Through Hole, 2Rows

针座 通孔 16 位置 0.100"（2.54mm）

得捷:
CONN HEADER VERT 16POS 2.54MM

欧时:
2.54mm TSW series PCB pin header, 16P

艾睿:
Look no further than the unshrouded TSW-108-07-F-D header connector from Samtec, a great tool to use when board-to-board interconnects is required. This HDR connector&s;s 16 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a maximum voltage rating of 550 VAC. This is a 2-row connector. Its pitch is 2.54 mm. It has a straight body orientation. It has a header type gender. This device has a maximum current rating of 6.3 A/contact. This product comes packaged in bulk, so the parts will be stored loosely. TSW-108-07-F-D is housed in black polyester. It uses the solder termination method. This product is 20.32 mm long, 8.38 mm tall and 5.08 mm deep. This connector has an operating temperature of -55 to 125 °C.

安富利:
Conn Unshrouded Header HDR 16 POS 2.54mm Solder ST Thru-Hole

Newark:
# SAMTEC  TSW-108-07-F-D  Board-To-Board Connector, 2.54 mm, 16 Contacts, Header, TSW Series, Through Hole, 2 Rows
