TIM100

BLOCK  TIM100  变压器, 隔离型 100VA

The is a 100VA Isolating Transformer with single 230V primary, twin 115V secondary windings for series or parallel connection. This resin encapsulated transformer features integrated overload protection, screw terminals under cover with strain relief, short circuit proof and manufactured as per IEC 61558-2-4, DIN EN 61558-2-4 and VDE 0570 part 2-4 standards. The TIM Series transformer can be used for the safe electrical isolation of the input and output sides and to set up protective separation as a protective measure in accordance with VDE 0100. Since the transformer is encapsulated in resin it acts as a very good moisture protection and low noise.

.

IP20 Protection rating

.

50 to 60Hz Frequency range

.

40°C Maximum ambient temperature
