TMM-107-01-L-D

SAMTEC TMM-107-01-L-D Board-To-Board Connector, 2mm, 14Contacts, Header, TMM Series, Through Hole, 2Rows

针座 通孔 14 位置 0.079"（2.00mm）

得捷:
CONN HEADER VERT 14POS 2MM

艾睿:
Think of Samtec&s;s unshrouded TMM-107-01-L-D header connector the next time you&s;re concerned about accidentally shorting out pins on your printed circuit. This HDR connector&s;s 14 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a header type gender. This is a 2-row connector. It has a straight body orientation. Its pitch is 2 mm. It has a maximum voltage rating of 500 VAC. This device has a maximum current rating of 5.5 A/contact. This product comes packaged in bulk, so the parts will be stored loosely. This product is 14 mm long, 4.7 mm tall and 3.94 mm deep. It uses the solder termination method. This connector has an operating temperature of -55 to 125 °C. TMM-107-01-L-D is housed in black liquid crystal polymer.

安富利:
Conn Unshrouded Header HDR 14 POS 2mm Solder ST Thru-Hole

Verical:
Conn Unshrouded Header HDR 14 POS 2mm Solder ST Top Entry Thru-Hole Bulk

Newark:
# SAMTEC  TMM-107-01-L-D  Board-To-Board Connector, 2 mm, 14 Contacts, Header, TMM Series, Through Hole, 2 Rows
