TMM-104-01-L-D

SAMTEC TMM-104-01-L-D Board-To-Board Connector, 2mm, 8Contacts, Header, TMM Series, Through Hole, 2Rows

针座 通孔 8 位置 0.079"（2.00mm）

得捷:
CONN HEADER VERT 8POS 2MM

欧时:
2.00 mm Low Profile Terminal Strip

艾睿:
This unshrouded TMM-104-01-L-D header connector from Samtec reduces the possibility of accidentally shorting pins when a board is being used. This HDR connector&s;s 8 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a straight body orientation. It has a maximum voltage rating of 500 VAC. It has a header type gender. Its pitch is 2 mm. This is a 2-row connector. This device has a maximum current rating of 5.5 A/contact. This product comes packaged in bulk, so the parts will be stored loosely. TMM-104-01-L-D is housed in black liquid crystal polymer. It uses the solder termination method. This product is 8 mm long, 4.7 mm tall and 3.94 mm deep. This connector has an operating temperature of -55 to 125 °C.

安富利:
Conn Unshrouded Header HDR 8 POS 2mm Solder ST Thru-Hole

Chip1Stop:
Conn Unshrouded Header HDR 8 POS 2mm Solder ST Thru-Hole Automotive Bulk

Newark:
# SAMTEC  TMM-104-01-L-D  Board-To-Board Connector, 2 mm, 8 Contacts, Header, TMM Series, Through Hole, 2 Rows
