TMM-105-01-L-D

SAMTEC TMM-105-01-L-D Board-To-Board Connector, 2mm, 10Contacts, Header, TMM Series, Through Hole, 2Rows

针座 通孔 10 位置 0.079"（2.00mm）

欧时:
2.00 mm Low Profile Terminal Strip

得捷:
CONN HEADER VERT 10POS 2MM

艾睿:
As an added safety precaution, the unshrouded TMM-105-01-L-D header connector from Samtec will prevent and protect components on your circuit board from accidentally touching each other. This HDR connector&s;s 10 contacts that are made out of phosphor bronze and plated with gold over nickel. Its pitch is 2 mm. It has a maximum voltage rating of 500 VAC. It has a header type gender. This is a 2-row connector. It has a straight body orientation. This device has a maximum current rating of 5.5 A/contact. This product comes packaged in bulk, so the parts will be stored loosely. It uses the solder termination method. This connector has an operating temperature of -55 to 125 °C. This product is 10 mm long, 4.7 mm tall and 3.94 mm deep. TMM-105-01-L-D is housed in black liquid crystal polymer.

安富利:
Conn Unshrouded Header HDR 10 POS 2mm Solder ST Thru-Hole

Newark:
# SAMTEC  TMM-105-01-L-D  Board-To-Board Connector, 2 mm, 10 Contacts, Header, TMM Series, Through Hole, 2 Rows
