TMM-106-01-L-D

SAMTEC TMM-106-01-L-D Board-To-Board Connector, 2mm, 12Contacts, Header, TMM Series, Through Hole, 2Rows

针座 通孔 12 位置 0.079"（2.00mm）

得捷:
CONN HEADER VERT 12POS 2MM

欧时:
2.00 mm Low Profile Terminal Strip

艾睿:
Mounting this unshrouded TMM-106-01-L-D header connector from Samtec to your printed circuit board can help you support multiple physical configuration options. This HDR connector&s;s 12 contacts that are made out of phosphor bronze and plated with gold over nickel. This is a 2-row connector. It has a header type gender. It has a maximum voltage rating of 500 VAC. Its pitch is 2 mm. It has a straight body orientation. This device has a maximum current rating of 5.5 A/contact. This product comes packaged in bulk, so the parts will be stored loosely. This connector has an operating temperature of -55 to 125 °C. This product is 12 mm long, 4.7 mm tall and 3.94 mm deep. It uses the solder termination method. TMM-106-01-L-D is housed in black liquid crystal polymer.

安富利:
Conn Unshrouded Header HDR 12 POS 2mm Solder ST Thru-Hole

Verical:
Conn Unshrouded Header HDR 12 POS 2mm Solder ST Thru-Hole Automotive Bulk

Newark:
# SAMTEC  TMM-106-01-L-D  Board-To-Board Connector, 2 mm, 12 Contacts, Header, TMM Series, Through Hole, 2 Rows

Online Components:
Conn Unshrouded Header HDR 12 POS 2mm Solder ST Thru-Hole Automotive Bulk

Electro Sonic:
Conn Unshrouded Header HDR 12 POS 2mm Solder ST Thru-Hole Automotive Bulk
