TSW-136-14-L-D

集管和线壳 .100" Terminal Strip

针座 通孔 72 位置 0.100"（2.54mm）

得捷:
CONN HEADER VERT 72POS 2.54MM

贸泽:
集管和线壳 .100" Terminal Strip

艾睿:
Reduce safety concerns with this unshrouded TSW-136-14-L-D header connector from Samtec which will reduce the possibility of accidentally shorting pins when a printed circuit board is being used. This HDR connector&s;s 72 contacts that are made out of phosphor bronze and plated with gold over nickel. This is a 2-row connector. It has a maximum voltage rating of 550 VAC. It has a header type gender. It has a straight body orientation. Its pitch is 2.54 mm. This device has a maximum current rating of 6.3 A/contact. This product comes packaged in bulk, so the parts will be stored loosely. This connector has an operating temperature of -55 to 125 °C. It uses the solder termination method. TSW-136-14-L-D is housed in black polyester. This product is 91.44 mm long, 10.67 mm tall and 5.08 mm deep.

Chip1Stop:
Conn Unshrouded Header HDR 72 POS 2.54mm Solder ST Thru-Hole Bulk

Verical:
Conn Unshrouded Header HDR 72 POS 2.54mm Solder ST Top Entry Thru-Hole Bulk

Newark:
# SAMTEC  TSW-136-14-L-D  Board-To-Board Connector, 2.54 mm, 72 Contacts, Header, TSW Series, Through Hole, 2 Rows

Online Components:
Conn Unshrouded Header HDR 72 POS 2.54mm Solder ST Thru-Hole Bulk

Electro Sonic:
Conn Unshrouded Header HDR 72 POS 2.54mm Solder ST Thru-Hole Bulk
