TSW-130-07-L-D

SAMTEC TSW-130-07-L-D Board-To-Board Connector, 2.54mm, 60Contacts, Header, TSW Series, Through Hole, 2Rows

针座 通孔 60 位置 0.100"（2.54mm）

欧时:
Classic PCB HDR Strips 0.100"

得捷:
CONN HEADER VERT 60POS 2.54MM

艾睿:
Protect your printed circuit boards from accidental damages with Samtec&s;s unshrouded TSW-130-07-L-D header connector. This HDR connector&s;s 60 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a straight body orientation. This is a 2-row connector. Its pitch is 2.54 mm. It has a maximum voltage rating of 550 VAC. It has a header type gender. This device has a maximum current rating of 6.3 A/contact. This connector has an operating temperature of -55 to 125 °C. TSW-130-07-L-D is housed in black polyester. This product is 76.2 mm long, 8.38 mm tall and 5.08 mm deep. It uses the solder termination method.

安富利:
Conn Unshrouded Header HDR 60 POS 2.54mm Solder ST Thru-Hole

Newark:
# SAMTEC  TSW-130-07-L-D  Board-To-Board Connector, 2.54 mm, 60 Contacts, Header, TSW Series, Through Hole, 2 Rows
