TSW-126-08-G-D

SAMTEC TSW-126-08-G-D Board-To-Board Connector, 2.54mm, 52Contacts, Header, TSW Series, Through Hole, 2Rows

针座 通孔 52 位置 0.100"（2.54mm）

得捷:
CONN HEADER VERT 52POS 2.54MM

艾睿:
Mount this unshrouded TSW-126-08-G-D header connector from Samtec on a jumper post on your PCB to support physical configuration options. This HDR connector&s;s 52 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a straight body orientation. Its pitch is 2.54 mm. It has a maximum voltage rating of 550 VAC. This is a 2-row connector. It has a header type gender. This device has a maximum current rating of 6.3 A/contact. This connector has an operating temperature of -55 to 125 °C. It uses the solder termination method. TSW-126-08-G-D is housed in black polyester. This product is 66.04 mm long, 8.38 mm tall and 5.08 mm deep.

安富利:
Conn Unshrouded Header HDR 52 POS 2.54mm Solder ST Thru-Hole

Newark:
# SAMTEC  TSW-126-08-G-D  Board-To-Board Connector, 2.54 mm, 52 Contacts, Header, TSW Series, Through Hole, 2 Rows
