TST-115-01-G-D

SAMTEC TST-115-01-G-D Wire-To-Board Connector, 2.54mm, 30Contacts, Header, TST Series, Through Hole, 2Rows

Connector Header Through Hole 30 position 0.100" 2.54mm

得捷:
CONN HEADER 30POS .100" T/H GOLD

艾睿:
Support physical configuration options for jumper posts by mounting this shrouded TST-115-01-G-D header connector from Samtec. This HDR connector&s;s 30 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a header type gender. This is a 2-row connector. It has a straight body orientation. Its pitch is 2.54 mm. This device has a maximum current rating of 3.4 A/contact. This product comes packaged in bulk, so the parts will be stored loosely. TST-115-01-G-D is housed in black polyester. This connector has an operating temperature of -55 to 125 °C. It uses the solder termination method. This product is 45.72 mm long, 9.27 mm tall and 9.27 mm deep.

Newark:
# SAMTEC  TST-115-01-G-D  Wire-To-Board Connector, 2.54 mm, 30 Contacts, Header, TST Series, Through Hole, 2 Rows
