TSW-115-05-G-D

SAMTEC TSW-115-05-G-D Board-To-Board Connector, 2.54mm, 30Contacts, Header, TSW Series, Through Hole, 2Rows

针座 通孔 30 位置 0.100"（2.54mm）

得捷:
CONN HEADER VERT 30POS 2.54MM

艾睿:
Support physical configuration options for jumper posts by mounting this unshrouded TSW-115-05-G-D header connector from Samtec. This HDR connector&s;s 30 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a maximum voltage rating of 550 VAC. It has a header type gender. Its pitch is 2.54 mm. This is a 2-row connector. It has a straight body orientation. This device has a maximum current rating of 6.3 A/contact. This product comes packaged in bulk, so the parts will be stored loosely. This product is 38.1 mm long, 5.21 mm tall and 5.08 mm deep. This connector has an operating temperature of -55 to 125 °C. It uses the solder termination method. TSW-115-05-G-D is housed in black polyester.

Newark:
# SAMTEC  TSW-115-05-G-D  Board-To-Board Connector, 2.54 mm, 30 Contacts, Header, TSW Series, Through Hole, 2 Rows
